Description

All Electric Roof Mount Bus Air Conditioning

Model EKX-18
Application L6m ~ 7m
Cooling features
Cooling capacity 12KW/10,000Kcal/39,674Btu/h
Outdoor air parameter 35℃
Indoor air parameter 27℃, relative humidity 60%
Voltage DC24V
Chassis voltage
Inpput power ≤4KW
Refrigerant R407c
Compressor/Displacement Highly/34cc
Condensor
Micro channel
3 x fan motors
Evaporator Internally grooved copper tubing with aluminum fins
Airflow
4 x fan motors
Hi:4000m3/h
Expansion valve Danfoss
Safety device
HP HP:3.2MPa
LP LP:0.18MPa
Exhaust temp. protection 115℃
Temperature control system Third gear wind speed control
Overall dimension 2826*1620*195mm
Weight 145KG
Standard mdoel with cooling only, heating function is optional
